SAMD21 M0-Mini

This simple set for 3D printer base on microcontroller Mega 2560 + RAMPS 1.4 + motor drivers, it is a solution for RepRap projects.

As low as $12.99
Availability: In stock
SKU
0G-00005516
SAMD21 M0-Mini is available to buy in increments of 1

The RobotDyn SAMD21 M0-Mini represents a powerful, 32-bit extension of the Arduino UNO platform, but to small size like Micro or Nano. The board is powered by Atmel’s SAMD21 MCU, featuring a 32-bit ARM Cortex® M0 core.
Compatible with Arduino M0.
The SAMD21 M0-Mini board expands the family by providing increased performance, enabling a variety of project opportunities for devices, and acts as a great educational tool for learning about 32-bit application development.
The Zero applications span from smart IoT devices, wearable technology, high-tech automation, to crazy robotics. The board is powered by Atmel’s SAMD21 MCU, which features a 32-bit ARM Cortex® M0+ core.

Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account
Fill in your delivery details to check available shipping options and calculate rates for this product. Total delivery fee for your order, you can find in cart.

Specifications

Microcontroller ATSAMD21G18 48pins LQFP
Power Out 3.3V-800mA
Power IN. USB 5V
Power IN. VIN/DC Jack 5V
Power Consumption 3.3V 220mA
Logic Level 3.3V
USB Micro USB
Clock Frequency 48MHz
Operating Supply Voltage 3.3V
GPIO 25
Digital I/O 19(12-PWM)
Analog I/O 6
Data RAM Type/Size 32Kb
Data ROM Type/Size 256Kb
Interface Type ISP
Operating temperature −40С°/+85С°
Length×Width 56.5×18mm

Documents

Dimensional drawing

Dimensions SAMD21 M0-Mini Dimensions SAMD21 M0-Mini

Pinout

Pinout SAMD21 M0-Mini Pinout SAMD21 M0-Mini

Schematic

Schematic of SAMD21 M0-Mini
