Angle front (Mega 2560 PRO (Embed) CH340G/ATmega2560-16AU (Arduino-compatible board)

Mega 2560 PRO (Embed) CH340G/ATmega2560-16AU

NANO V3 CH340

NANO V3 CH340

Mega 2560 PRO MINI, ATmega2560-16AU

The Mega Pro MINI CH340G / ATmega2560 board is based on the ATmega2560 microcontroller and the USB-UART adapter CH340. The board is compatible with Arduino Mega 2560.

As low as $8.69
Availability: In stock
SKU
8bcfb90a-c46b-11e6-ab3c-10c37b90f38d

General information

The Mega Pro MINI CH340G / ATmega2560 board is based on the ATmega2560 microcontroller and the USB-UART adapter CH340. The board is compatible with Arduino Mega 2560.

The board has a compact form factor of 38X52mm and is an excellent solution for developing projects based on ATmega2560.

The Mega Pro Mini functionalities are identical to the Arduino Mega 2560. Even though it is an Embed board, it is solid stable as the Mega Board. It uses the original chip, and a 16 MHz high-quality quartz resonators is present on the board.

The board doesn’t have a USB interface. In order to connect Pro MINI to a PC you have to use USB-TTL converter.

The board can be powered through the power PIN Vin). The maximum output current upon 5V is around 800mA, while on the 3.3V it is about 800mA.

In the picture below, you can see the difference in size between the MINI and the usual Mega.

Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account

Specifications

Microcontroller ATmega2560
USB-TTL converter CH340
Power Out 5V-800mA
Power IN. 5V
Power IN. VIN/DC Jack 5V
Power Consumption 5V 220mA
Logic Level 5V
Clock Frequency 16MHz
Operating Supply Voltage 5V
Digital I/O 54
Analog I/O 16
Memory Size 256kb
Data RAM Type/Size 8Kb
Data ROM Type/Size 4Kb
Interface Type ISP
Operating temperature −40С°/+85С°
Length×Width 38×52mm

Documents

Dimensional drawing

Size Mega 2560 PRO MINI/ATmega2560-16AU Size Mega 2560 PRO MINI/ATmega2560-16AU

Input and Output (I/O) diagram

Pins I/O dMega 2560 PRO MINI/ATmega2560-16AU Pins I/O diagram Mega 2560 PRO MINI/ATmega2560-16AU

Schematic

Schematics Mega 2560 PRO MINI/ATmega2560-16AU

Eagle CAD library

Eagle CAD library for Mega 2560 PRO MINI/ATmega2560-16AU
