16 Keys Capacitive touch TTP229 I2C module

$1.59
Availability: In stock
SKU
6970622930891
  • Buy 5 for $1.49 each and save 6%
  • Buy 15 for $1.39 each and save 13%
  • Buy 35 for $1.29 each and save 19%

TP229 Capacitive Touch Module have 16 capacitive inputs. The module has two working modes. Module use only 16 key mode. For connection to microcontrollers (Arduino, Raspberry, STM) use the I2C interface.
To capacitive inputs can connect special capacitive KeyPad, any metal objects, prints of electronic ink or pens, fruits.
In our catalog have 16 key touch KeyPad or disk KeyPad.

Documents

Dimensional drawing

Dimensions 	16 Keys Capacitive touch TTP229 I2C module	Dimensions 	16 Keys Capacitive touch TTP229 I2C module

Pinout

Pinout 	16 Keys Capacitive touch TTP229 I2C module	Pinout 	16 Keys Capacitive touch TTP229 I2C module

Schematic

Schematic of 	16 Keys Capacitive touch TTP229 I2C module
